Bulk CCTV Cable OEM Manufacturer
| Place of Origin: | Hangzhou, China |
|---|---|
| Brand Name: | OEM Produce |
| Certification: | CPR. CE. ROHS2.0 |
| Model Number: | 2.5mm2 Fire Alarm Cable |
| Minimum Order Quantity: | 10km |
| Price: | FOB Shanghai Price: 165.0USD/500m |
| Packaging Details: | 100M. 200M. 300M. 1000FT. 500M. Reel |
| Delivery Time: | 20days after deposit |
| Payment Terms: | TT. LC |
| Supply Ability: | 5000km/ Month |
| Application: | Flame And Smoke Alarm System | Conductor Material: | 1.78mm Solid CU |
|---|---|---|---|
| Insulation Material: | PE Or FR PVC | Shielded: | AL Foil |
| Earth Wire: | TCCA Or CCA Drain Wire | Oprating Voltage: | DC 12V/ AC 24V |
| Sheath: | Fire Resistance PVC Or LSZH | Jacket Color: | Orange Or Red |
| Type: | Low Voltage FR Electric Wire | Core: | 2 Core |
| High Light: | fire proof cable,flame retardant low smoke cables |
||
APPLICATION:
1. Addressable fire alarm systems
2. Fire alarm systerms
3. Voice communications
4. Smoke detectors
These cables are used for installation in fire systems for connecting fire alarms etc. The cable can be installed in dry and moist areasas well for fixed open air installation. This cable type with electrostatic screening (St) protects the transmission circuits against externelectrical interferences.
| Shielded Fire Alarm Wire | ||||||
| No. | Inner Conductor | Insulation | Earth Wire | Jacket | ||
| Nominal Area | Core No. | Construction | Outer Dia. | Outer Diameter | ||
| mm² | No./mm | mm | No./mm | mm | ||
| 1 | 0.2 | 2 | 1/0.5 | 1.5 | 1/0.4 | 4.2 |
| 2 | 0.35 | 2 | 1/0.67 | 1.8 | 1/0.4 | 5 |
| 3 | 0.5 | 2 | 1/0.8 | 2 | 1/0.4 | 5.4 |
| 4 | 0.75 | 2 | 1/0.98 | 2.4 | 1/0.4 | 6.4 |
| 5 | 1 | 2 | 1/1.13 | 2.7 | 1/0.8 | 7.2 |
| 6 | 1.5 | 2 | 1/1.38 | 2.9 | 1/0.8 | 7.6 |
| 7 | 2.5 | 2 | 1/1.78 | 3.3 | 1/0.8 | 8.6 |
| 8 | 0.2 | 4 | 1/0.5 | 1.5 | 1/0.4 | 6.4 |
| 9 | 0.35 | 4 | 1/0.67 | 1.8 | 1/0.4 | 7.5 |
| 10 | 0.5 | 4 | 1/0.8 | 2 | 1/0.4 | 8.2 |
| 11 | 0.75 | 4 | 1/0.98 | 2.4 | 1/0.4 | 9.7 |
| 12 | 1 | 4 | 1/1.13 | 2.7 | 1/0.8 | 10.9 |
| 13 | 1.5 | 4 | 1/1.38 | 2.9 | 1/0.8 | 11.6 |
| 14 | 2.5 | 4 | 1/1.78 | 3.3 | 1/0.8 | 13.0 |
|
Question and Answer
|
|
| Are you a factory? |
yes we are a cables factory in Hangzhou China. We manufacturer and export cables directly.
|
| Do you offer sample for testing? |
yes, we can offer 2meter cable sample for free. But if need 1 roll 100m or more sample, please place a sample order. We will make a sample accroding to your requiments, but need charge the sample fee.
|
| How can we buy fire alarm cables? |
We are factory in China, we produce and export cables to global market. We deliver goods by sea transportation. Right now we not yet have any agents in overseas.
|
| Some special wire can be produced? |
Yes, our engigeers will solve your problem. And we can produce according to your specification or drawer.
|
| OEM can be accepted? |
Yes we offer OEM service. We can make cables with your own brand. Such as ourter packing, label, mark on cable sheath and drums all can use your design.
|
If you have technical support from an engineer, please let us know the type of cables you need, the inner conductor, the braiding coverage, the jakcet material and color, the packing length and design, and the application. We will help you choose the most suitable cable.
If you are not sure about certain specifications of the electric cables, please let us know your inquiry and we are very happy to give you professional technical advice and support services. Our company offer specific cables and wires consulting, design, OEM and manufacturing based on the customer's requirements and application scenarios to help customers create more business opportunities.
